Acura TSB 00-014

Acura Service Bulletin 00-014

Date: April 24, 2000
Applies To: 1999 Acura 3.2TL – ALL
2000 Acura 3.2TL – From VIN 19UUA5…YA000001 through YA008807

Squeak or Creak From the Driver's Seat


Symptom

The driver’s seat may squeak when the occupant moves, or creak when the seat is adjusted to its lowest position.

Probable Cause

Noise may be caused by the seat cushion rubbing against the seat frame, or by the seat belt buckle mounting bolt contacting the frame.

Corrective Action

Apply wool felt tape to the seat frame. If creaking is present, bend the seat belt buckle mounting flange outward.


Required Materials

Wool Felt Tape: P/N 06993‑SA5‑000 (one roll repairs approximately four vehicles)


Warranty Claim Information

Operation Number:851003
Flat Rate Time:0.6 hour
Failed Part:81660-S0K-A01
Defect Code:042
Contention Code:B07
Template ID:00-014A
Skill Level:Repair Technician

Out-of-warranty repairs may qualify for goodwill consideration with prior approval.


Repair Procedure

  1. Lower the driver’s seat fully and remove it from the vehicle.
  2. Remove the right side cover and inspect for contact marks between the seat belt buckle mounting bolt and the seat frame.


  • If contact marks are present, bend the mounting flange (step 3).
  • If no marks are present, proceed to step 4.
  1. With the seat supported, clamp the seat rail and bend the buckle mounting flange outward to prevent contact.


  1. Remove the side covers from the seat frame.


  1. Remove the seat cushion from the frame.
  2. Cut two strips of wool felt tape (410 × 15 mm) and apply them to both sides of the frame where rubbing occurs.


  1. Reassemble the seat and reinstall it in the vehicle.

Customer Information: This bulletin is intended for trained technicians with proper tools and equipment. Clients should consult an authorized Acura dealer to determine applicability.

Sunday, March 1, 2026

Acura TSB 00-013

Acura Service Bulletin 00-013

Date: July 25, 2007
Applies To: 1996–2004 Acura 3.5RL – ALL
1997–2005 Acura NSX – ALL

Immobilizer System (Type 1)

This bulletin explains the operation, components, key programming procedures, and troubleshooting for the Type 1 immobilizer system used on these vehicles. It also outlines what to do when keys are lost, when modules are replaced, and how to temporarily start the engine without a programmed key.


Warranty Claim Information

No warranty claim procedures apply; this bulletin is informational.


Immobilizer System Components

The system includes master keys, a valet key, a learning key, an indicator, a receiver, a control unit, and the ECM/PCM. Each component plays a role in verifying the key’s transponder code before allowing the engine to start.



Immobilizer System Indicator

The indicator shows system status when a key is inserted. Programmed keys cause normal illumination; unprogrammed keys cause blinking and prevent engine cranking.



Immobilizer Receiver

The receiver energizes the key’s transponder and sends its ID code to the control unit. It contains no logic and does not require programming when replaced.



Immobilizer Control Unit

The control unit verifies transponder codes, controls the starter cut relay, and communicates with the ECM/PCM to authorize engine start.



ECM/PCM

The ECM/PCM must recognize the immobilizer control unit’s serial code. Both modules must mutually authenticate before fuel and ignition systems are enabled.


Consequences of a Lost Key

The bulletin outlines several scenarios involving lost programmed keys or learning keys. Depending on what is missing, the immobilizer control unit may need replacement, or key‑adding capabilities may be limited.


Adding Programmed Ignition Keys

Keys can be added using either:

  • The Ilco Immobilizer Key Code Duplicator (preferred)
  • The Honda Diagnostic System (HDS), which rewrites the immobilizer control unit

Detailed preparation steps and programming sequences are provided in the bulletin.


Clearing Transponder Codes of Lost Keys

If a client loses one or more programmed keys, the immobilizer control unit should be rewritten using the HDS so that lost keys can no longer start the engine.


Starting the Engine Without a Programmed Ignition Key

A temporary start procedure is available using a cut non‑transponder key and the Immobilizer Brake/Access Code. This allows the vehicle to be driven directly to a dealership for repair.


Replacing the Immobilizer Control Unit

When the control unit is replaced, it must be rewritten with the HDS so it can recognize the vehicle’s programmed keys and communicate with the ECM/PCM.


Replacing the ECM/PCM

After ECM/PCM replacement, the module must be rewritten with the HDS to synchronize immobilizer serial codes. The idle learn procedure must then be performed.


Client Situation and Required Items Chart

The bulletin includes a detailed chart listing common immobilizer‑related situations and the required tools, keys, and procedures for each. This includes lost keys, faulty components, and lock cylinder issues.

Client SituationRequired Items
Client wants additional keysKey duplicator or HDS, learning key, programmed keys, key blanks
Client lost a programmed keyLearning key, remaining keys, HDS
Client lost all programmed keysImmobilizer unit set, key cutter, HDS
Learning key inserted accidentallyImmobilizer unit set, keys, HDS
Immobilizer control unit faultyImmobilizer unit set, keys, HDS
Immobilizer receiver faultySteering lock assembly
ECM/PCM faultyReplacement ECM/PCM, one programmed key, HDS
Ignition key cylinder faultySteering lock assembly or key cylinder set
Other locks damagedKey cylinder set

Customer Information: This bulletin is intended for trained technicians with proper tools and equipment. Clients should consult an authorized Acura dealer for diagnosis and repair.

Sunday, February 1, 2026

Acura TSB 00-012

Acura Service Bulletin 00-012

Date: March 6, 2000
Applies To: 2000 Acura Models – ALL

2000 Acura Paint Codes

This bulletin provides paint codes, descriptions, and touch‑up paint part numbers for all 2000 Acura models. Paint formulas are determined by each paint manufacturer; suppliers are listed at the end of the bulletin.


Sayama (Japan) Produced RL Models

The following table summarizes paint codes, color names, and touch‑up paint numbers for RL models built in Sayama.

Paint CodeDescriptionTouch‑up Paint
B-92PNighthawk Black Pearl08703-B92PPAA
B-93PMonterey Blue Pearl08703-B93PPAA
G-97PVermont Green Pearl08703-G97PPAA
NH-552MSebring Silver Metallic08703-NH552MAA
NH-624PPremium White Pearl08703-NH624PA
R-504PRuby Red Pearl08703-R504PAA
YR-524MNaples Gold Metallic08703-YR524MA

Suzuka (Japan) Produced Integra Models

Paint codes and touch‑up paint numbers for Integra models built in Suzuka.

Paint CodeDescriptionTouch‑up Paint
B-97MVoltage Blue Metallic08703-B97MMAA
G-95PClover Green Pearl08703-G95PPAA
NH-578Taffeta White08703-NH578AA
NH-583MVogue Silver Metallic08703-NH583MAA
NH-592PFlamenco Black Pearl08703-NH592PAA
PB-76PDark Violet Pearl08703-PB76PAA
R-81Milano Red08703-R81PPAA
R-505PCayenne Red Pearl08703-R505PAA
Y-56Phoenix Yellow08703-Y56AA

Paint Process Codes

Paint descriptions include a number indicating the manufacturing process:

  • 1: Two‑stage — clear coat over color coat
  • 2: Two‑stage — tinted clear coat over color coat
  • 3: Single‑stage — no clear coat

Marysville (U.S.) Produced TL Models

Paint codes and touch‑up paint numbers for TL models built in Marysville.

Paint CodeDescriptionTouch‑up Paint
B-92PNighthawk Black Pearl08703-B92PPAA
B-93PMonterey Blue Pearl08703-B93PPAA
G-87PDark Emerald Pearl08703-G87PPAA
G-91MLaguna Green Metallic08703-G91MMAA
NH-578Taffeta White08703-NH578AA
NH-603PWhite Diamond Pearl08703-NH603PAA
NH-623MSatin Silver Metallic08703-NH623MAA
R-507PFirepepper Red Pearl08703-R507PAA
YR-524MNaples Gold Metallic08703-YR524MA

Tochigi (Japan) Produced NSX Models

Paint codes and touch‑up paint numbers for NSX models built in Tochigi.

Paint CodeDescriptionTouch‑up Paint
B-501PMonaco Blue Pearl08703-B501PPAA
NH-547Berlina Black08703-NH547AA
NH-565Grand Prix White08703-NH565AA
NH-630MSilverstone Metallic08703-NH630MAA
R-510New Formula Red08703-R510AA
Y-52PSpa Yellow Pearl08703-Y52PPAA

Paint Supplier Contact Information

Paint suppliers and technical support phone numbers are provided for formula and color‑matching assistance.

Paint SupplierPhone Number
Dupont Color/Technical Hotline800-3 DUPONT
PPG Color Library440-572-6100
PPG Technical Service440-572-6111
BASF Call Center800-825-3000
Sherwin Williams Customer Assistance800-798-5872
Martin Senour Customer Assistance800-526-6704
Sikkens Color Helpline800-618-1010
Spies-Hecker Color Questions800-447-7437
General Questions516-777-7100
Standox Color Questions800-551-9296
Standox General Questions734-454-4556
ICI Autocolor800-647-6050

American Honda does not endorse any specific paint company; this information is provided for reference only.

Thursday, January 1, 2026

Acura TSB 00-010

Acura Service Bulletin 00-010

Date: February 28, 2000
Applies To: 1999 Acura 3.5RL – ALL
2000 Acura 3.5RL – From VIN JH4KA…YC000001 through YC006683

Squeak or Crunch From the Driver's Seat


Symptom

The driver’s seat-back may produce squeaking or crunching noises when the occupant moves.

Probable Cause

Seat cushion foam rubs against the seat-back frame, creating noise.

Corrective Action

Cloth tape must be applied to specific areas of the seat-back frame to eliminate rubbing.


Parts Information

Back Cover Clip (3 required): P/N 91566-SP0-003

Required Materials

Scotch Automotive Cloth Tape (3M P/N 021200‑06980) is required. This tape withstands interior temperature extremes. One roll repairs approximately three seat-backs.


Warranty Claim Information

Operation Number: 851007

Flat Rate Time:1.2 hour
Failed Part:81522-SZ3-A81
Defect Code:042
Contention Code:B07
Template ID:00-010A
Skill Level:Repair Technician

Out-of-warranty repairs may qualify for goodwill consideration with prior approval.


Diagnosis

While seated, the technician moves their shoulders side-to-side. If noise is present, proceed to the repair procedure.


Repair Procedure

  1. Remove the driver’s seat-back cover (per service manual instructions).
  2. Remove the foam cushion from the seat-back frame.
  3. Apply cloth tape to the frame at the locations where rubbing marks appear on the foam.


  1. Reinstall the foam cushion.
  2. Reinstall the seat-back cover.
  3. Install three new back cover clips and reinstall the cover.

Customer Information: This bulletin is intended for trained technicians with proper tools and equipment. Customers should consult an authorized Acura dealer to determine applicability.

Monday, December 1, 2025

Acura TSX 00-009

Acura Service Bulletin 00-009

Date: December 18, 2000
Applies To: 2001 Acura 3.2CL – ALL

2001 3.2CL: TQI and New Model Information

Supersedes 00‑009, dated April 10, 2000

Most features, equipment, and delivery procedures for the 2001 3.2CL are similar to other Acura models. This bulletin highlights items unique to the 2001 model and important service information.


Warranty Claim Information

None — this information is part of the Total Quality Inspection (TQI).


Fuse Installation

The BACKUP‑ACC fuse (40A) is removed during shipping and placed in the beverage holder. Install the fuse in the under‑hood fuse/relay box before driving the vehicle.

Important: The taillights will not operate until the fuse is installed.



Shift Lock Release

The shift lock release cover is removed for shipping and stored in a small bag with the Owner’s Manual. Install the cover during TQI.



Wheel Balance and Alignment

Type S wheels lack an exterior flange for mounting weights. Use:

  • Genuine Honda alloy weights on the inner flange
  • Tape weights for the outer flange
  • Alignment equipment mounted on the outer lip

Do Not Install Type S Wheels on Premium Models

The 17‑inch Type S wheels can damage the chassis and body of premium models. The Type S uses different suspension components designed for the larger wheels.


Side Airbags

Side airbags are located in the outer bolsters of the front seats. The passenger seat includes an Occupant Position Detection System (OPDS).


The system disables the passenger side airbag when:

  • A small child is seated with their head in the deployment path
  • An object of specific size/weight is on the seat

The SIDE AIRBAG indicator illuminates when disabled.


Remove Tag at TQI

Remove and discard the bar code tag from the passenger seat headrest during TQI.


Remote Activation of Driver’s Seat Memory

Each remote transmitter can activate Memory 1 or Memory 2 seat/mirror positions when unlocking the doors. Turn this feature on during TQI using the instructions printed on the back of each transmitter.



HVAC System

The redesigned HVAC system is quieter and more efficient. It includes a micron air filter that must be replaced during scheduled maintenance.


Premium Fuel Recommendation

This vehicle requires premium unleaded fuel (91+ octane). Lower octane should be used only in emergencies.


Service Connectors

The 2001 3.2CL includes three service connectors:

  • DLC (under cover between seat heater switches)
  • MES (back of driver’s fuse/relay box)
  • Multiplex Control Inspection Socket





PGM Tester Usage

The PGM Tester must have program card version SN010P or later.


Retrieving the Audio Unit Serial Number

To retrieve the serial number without removing the unit:

  1. Turn ignition to ACC (I).
  2. Turn on the audio unit; ensure “CODE” appears.
  3. Turn the unit off.
  4. Press and hold preset buttons 1 and 6, then turn the unit on.

The serial number displays in two 4‑digit groups.



VSA (Vehicle Stability Assist)

Type S models include VSA, which integrates ABS and TCS. The VSA indicator blinks during activation.



5‑Speed Automatic Transmission

The Type S transmission includes a heavy‑duty torque converter and increased 2nd‑gear clutch capacity. In sequential mode:

  • Manual 1–2 shifts are not allowed
  • Simultaneous driver/PCM shifts may cause a jump from 1st to 3rd

Fuel Tank Drain Bolt

This vehicle does not have a fuel tank drain bolt.


Headlight Mounts

If a headlight housing is reusable after an accident, an auxiliary bracket can be ordered separately.


Brake System Indicator

The indicator illuminates with ignition ON (II) and turns off after engine start if the parking brake is released.


Navigation System

Uses the same DVD‑based system as the 3.2TL. Refer to S/B 99‑041 for details.


Windshield Wiper Arms

Wipers rest below the hood line. To service blades, stop the wipers mid‑stroke by turning ignition OFF while they are moving.


In‑Dash CD Changer

All models include a 6‑disc in‑dash changer. Customers must follow loading instructions carefully.


Passenger’s Side Mirror

With the selector switch centered, the mirror tilts downward in reverse for improved visibility. Disable by leaving the switch in L or R.


Road Lamps

Road lamps turn on with the headlights (high or low beam). They are not fog lights or driving lights.

Saturday, November 1, 2025

Acura TSX 00-008

Acura Service Bulletin 00-008

Date: March 6, 2000
Applies To: All Models with L4 or V6 Engine and A/T with 44 mm I.D. Torque Converter Oil Seal

Torque Converter Oil Seal Installation Tool

The service manual procedure for installing the torque converter oil seal normally requires transmission disassembly. A new required special tool attaches to the existing 40 mm I.D. driver, allowing installation of the seal without removing the mainshaft or disassembling the transmission.

Required Special Tools

Seal Driver Attachment: T/N 07XAD‑001000A
(Shipped to all dealers March 2000 as a required special tool)
40 mm I.D. Driver: T/N 07746‑0030100

Ordering Information

Additional seal driver attachments may be ordered through normal American Honda parts procedures.

Warranty Claim Information

None — this bulletin is informational only.


Procedure

1. Remove the transmission (see section 14 of the appropriate service manual).

2. Remove and discard the torque converter oil seal. Be careful not to damage the torque converter housing.

3. Select the appropriate replacement seal.


4. Press the long end of the seal driver attachment into the driver. Press the new seal onto the short end. Do not apply sealer to the seal or housing — the seal must be installed dry.


5. Slide the tool over the mainshaft as far as it will go.

6. Using a soft‑face hammer, lightly tap the driver until the seal is fully seated in the torque converter housing.

7. Reinstall the transmission.


Customer Information: This bulletin is intended for trained technicians with proper tools and equipment. Consult an authorized Acura dealer to determine applicability.

Wednesday, October 1, 2025

Acura TSB 00-007

Acura Service Bulletin 00-007

Date: April 3, 2000
Applies To: 1995–98 Acura 2.5TL – ALL
1996–98 Acura 3.2TL – ALL

Growling or Whining From the Rear Wheel(s)

Symptom

A growling or whining noise from one or both rear wheels while driving. The noise changes pitch with vehicle speed and is not affected by road conditions.

Probable Cause

Water drips down the brake caliper and contaminates the rear hub bearing seal.

Corrective Action

Replace the hub bearing unit, splash guard, spindle nut, and grease cap on both rear wheels.

Parts Information

Wheel Bearing Kit (1995–98 2.5TL): P/N 06427‑SW5‑305
Wheel Bearing Kit (1996–98 3.2TL): P/N 06427‑SZ5‑305

Each kit includes:
– 2 hub bearing units
– 2 splash guards (left & right rear)
– 2 spindle nuts
– 2 grease caps

Warranty Claim Information

OP# Description FRT Template ID
418154 Replace hub bearing unit, splash guard, spindle nut, and grease cap (both rear wheels, 2.5TL) 1.2 00-007A
418092 Test-drive the vehicle 0.3
418154 Replace hub bearing unit, splash guard, spindle nut, and grease cap (both rear wheels, 3.2TL) 1.2 00-007B
418092 Test-drive the vehicle 0.3

Failed Part:P/N 42200‑SW5‑951
Defect Code:042
Contention Code:B07
Skill Level:Repair Technician

Out of warranty: Repairs may qualify for goodwill consideration with prior approval.


Diagnosis

Test‑drive the vehicle at a steady speed above 35 mph. Turn the steering wheel gently side‑to‑side (11 o’clock to 1 o’clock) to shift weight between the rear wheels.

  • If no growling or whining is heard, disregard this bulletin and inspect other causes.
  • If noise is present, proceed to the repair procedure.

Repair Procedure

1. Replace the hub bearing unit, splash guard, spindle nut, and grease cap on both rear wheels. Refer to the appropriate service manual.

2. Test‑drive the vehicle to confirm the noise is gone.


Customer Information: This bulletin is intended for trained technicians with proper tools and equipment. Consult an authorized Acura dealer to determine applicability.

Monday, September 1, 2025

Acura TSB 00-006

Acura Service Bulletin 00-006

Date: May 1, 2000
Applies To: 1996–99 Acura SLX – ALL

Static From the Speakers While Adjusting the Power Mirrors

Symptom

Static comes from the speakers while adjusting the power mirrors with the engine running and the radio on.

Probable Cause

Inadequate noise suppression for the mirror power source.

Corrective Action

Install a noise suppression harness in line with the door harness going to each power mirror.

Parts Information

Noise Filter Radio Kit: P/N 8‑97224‑655‑0

Warranty Claim Information

Operation Number: 820055

Flat Rate Time:0.6 hour (both mirrors)
Failed Part:P/N 8‑97195‑911‑1
Defect Code:042
Contention Code:B07
Template ID:00‑006A
Skill Level:Repair Technician

Out of warranty: Repairs may qualify for goodwill consideration with prior approval.


Repair Procedure

1. Remove the tweeter assembly (two clips) and unplug its 2P connector.


2. Remove the power mirror (three bolts) and unplug its 8P connector.

3. Remove the front door trim panel.


4. Peel back the upper front corner of the plastic rain protector. Cut through the sealant if needed.

5. Pull the door wire harness for the power mirror out through the door opening.


6. Plug the noise suppression harness 8P connector into the door wire harness 8P connector.

7. Feed the other end of the noise suppression harness out through the door opening.


8. Plug the harness into the power mirror and reinstall the mirror. Torque the bolts to 8 N·m (6 lb‑ft).

9. Pull down on the door wire harness to remove slack. Fold the harness over itself and secure it to the 8P connector with a wire tie.


10. Reinstall the plastic rain protector.

11. Reinstall the front door trim panel.

12. Reinstall the tweeter assembly.

13. Repeat steps 1–12 for the other power mirror.

14. Start the engine and turn on the radio.

15. Adjust each power mirror and confirm no static is heard from the speakers.


Customer Information: This bulletin is intended for trained technicians with proper tools and equipment. Consult an authorized Acura dealer to determine applicability.

Friday, August 1, 2025

Acura TSB 00-005

Acura Service Bulletin 00-005

Date: March 27, 2000
Applies To: 1996–99 Acura 3.5RL (ALL)
2000 Acura 3.5RL – From VIN JH4KA9...YC000001 thru JH4KA9...YC005649

Rattle From the Moonroof

Symptom

Rattle from the rear of the moonroof while driving over rough or bumpy roads with the sunshade open.

Probable Cause

The friction‑reducing coating has worn off the rear edge of the moonroof rubber seal.

Corrective Action

Replace the moonroof glass.

Parts Information

Roof Glass Assembly: P/N 70200‑SZ3‑A01

Warranty Claim Information

Operation Number: 814110

Flat Rate Time:0.5 hour
Failed Part:P/N 70200‑SZ3‑A01
Defect Code:043
Contention Code:B07
Template ID:00‑005A
Skill Level:Repair Technician

Out of warranty: Repairs may qualify for goodwill consideration with prior approval.


Diagnosis

1. Open the sunshade.

2. Push up on the rear of the moonroof glass and release it several times while listening for a squeaking or crunching noise.

  • If no noise is heard, inspect for other causes.
  • If noise is present, continue to the repair procedure.

Repair Procedure

1. Close the moonroof completely.

2. Slide the sunshade fully rearward.

3. Remove the cover from the moonroof glass bracket (one plug, one screw). Remove the four flange nuts. Note the number and location of any shims, then remove them.


4. Repeat step 3 on the opposite side.

5. Carefully lift out the moonroof glass and discard it.


6. Install the new glass and reinstall any shims removed earlier. Torque the flange nuts to 9 N·m (7 lb‑ft).

7. Check alignment and glass height; adjust if necessary.

8. Check for water leaks.

9. Reinstall the bracket covers.


Customer Information: This bulletin is intended for trained technicians with proper tools and equipment. Consult an authorized Acura dealer to determine applicability.

Tuesday, July 1, 2025

Acura TSB 00-004

Acura Service Bulletin 00-004

Date: December 17, 2001
Applies To: 1999 Acura 3.2TL – ALL

3.2TL Warranty Extension: EGR Port Clogging

Supersedes 00‑004, dated October 26, 2001

Background

In some regions of the U.S., certain chemical properties of gasoline may cause the intake manifold EGR port to clog or the EGR valve to fail. When this occurs, the MIL may illuminate with DTC P0401 (insufficient EGR flow) or P1491 (insufficient EGR lift).

Warranty Extension Information

This warranty extension cancels the previous PCV hose routing Product Update Campaign. Do not install the PCV hose routing kit anymore.

American Honda is extending warranty coverage for EGR system issues to 8 years or 80,000 miles, whichever comes first. To qualify, the MIL must be on with one of the listed DTCs. Install the EGR pipe kit and file a claim per this bulletin.

Customer Notification

Owners of early‑production 1999 TLs (first ~25,000 VINs) will receive letters explaining the cancellation of the PUD and the new warranty extension. Remaining 1999 TL owners will receive similar letters. Examples of these letters appear at the end of this bulletin.

Corrective Action

Clean the EGR port and install the EGR pipe kit.

Parts Information

EGR Pipe Kit: P/N 06175‑P8E‑A00

Tool Information

EGR Pipe Installation Kit: T/N 07ZAD‑P8AA000

Kit Includes:
EGR Pipe Installation Tool – T/N 07ZAD‑P8AA100
Drill Bit – T/N 07ZAH‑P8AA100


Warranty Claim Information

Operation Number:120123
Flat Rate Time:1.5 hours
Failed Part:P/N 17100‑P8F‑A00
Defect Code:537
Contention Code:L40
Template ID:00‑004B
Skill Level:Repair Technician

Out of warranty: Repairs may qualify for goodwill consideration with prior approval.


Repair Procedure

1. Remove the intake manifold cover. Unplug the rear bank ignition coil 3P connectors and remove the rear ignition coil cover.


2. Disconnect the brake booster vacuum hose and the vacuum hose from the intake manifold.

3. Remove the throttle body (two nuts, two bolts). Leave all hoses and connectors attached. Discard the old gasket.


4. Remove the PCV valve. Remove the intake manifold (three nuts, six bolts).

5. Remove the end plates, IAT sensor, and boost plate. Retain all gaskets and O‑rings.


6. Cover the six ports on the bottom of the manifold with duct tape.


7. Use an 8 mm drill bit and carb cleaner to clean the EGR port by hand.

8. Coat the special drill bit with clean engine oil.

9. Insert the guide into the EGR port and drill through using steady pressure.


10. Remove aluminum chips and duct tape.

11. Thoroughly wash the manifold (EGR port, throttle body opening, runners). Dry with compressed air.


12. Insert the EGR pipe into the port.


13. Use the installation tool and a small hammer to drive the pipe in until flush.


14. Reinstall end plates (12 N·m), IAT sensor (18 N·m), and boost plate (12 N·m). Reinstall PCV hose if applicable.

15. Inspect and clean the EGR port in the injector base if clogged.

16. Disconnect the 6P connector and remove the EGR valve.


17. Install the new EGR valve with a new gasket (22 N·m). Reconnect the 6P connector.

18. Install the intake manifold with the original gasket. Torque bolts to 22 N·m in sequence.


19. Install the PCV valve.

20. Install the throttle body with a new gasket (22 N·m).

21. Reconnect vacuum hoses, ignition coil connectors, and covers.

22. Connect the PGM Tester and clear DTCs.

23. Override two‑trip detection:
1. Honda Systems → 2. SCS

24. Test‑drive the vehicle to confirm no new DTCs.


Customer Letter Examples

Two sample letters (for early and late 1999 TL owners) are included in the bulletin. These letters explain the cancellation of the PCV update and the new 8‑year/80,000‑mile EGR system warranty extension.

Sunday, June 1, 2025

Acura TSB 00-003

Acura Service Bulletin 00-003

Date: July 24, 2014
Document: BTB 21394-51940 (1407) REV‑1

MIL Comes On With DTC P1441

Supersedes 00‑003 dated June 5, 2000

Affected Vehicles

Year Model Trim VIN Range
1998–99 SLX ALL ALL

Revision Summary

The PGM Tester, Smart Cable, and software for SLX reprogramming are no longer available. Some generic scan tools may still work. If PCM updating is required, the PCM must be sent to the vendor for reprogramming.

Symptom

The MIL comes on and DTC P1441 (EVAP system flow during non‑purge) is stored.

Possible Causes

The PCM software does not compensate for fuel tank pressure sensor signal variation when fuel sloshes in a nearly full tank.

Corrective Action

Replace the 20‑to‑120‑ohm fuel sending unit with an 80‑to‑290‑ohm unit and have the PCM updated.

Warranty Claim Information

Operation Number Description Flat Rate Time Template ID Failed Part Number
310121 Replace fuel sending unit 0.7 00‑003A 8‑16244‑059‑0

Defect Code: 091
Symptom Code: C99
Skill Level: Repair Technician

Parts Information

Part Name Part Number Quantity
Fuel Sending Unit 8‑97193‑984‑1 1

Required Tools & Equipment

Honda no longer supports the diagnostic tool for this vehicle. Some generic tools may apply.


Required Materials

Part Name Part Number Quantity
Acura Brake Cleaner 08700‑9201A 1 (Cleans approx. two vehicles)

Diagnosis

Use a generic scan tool to retrieve the PCM broadcast code. Compare it to the following list:

PCM Broadcast Codes (20‑to‑120‑ohm sending units):
BZCD, BZCF
CKLB, CKLC
CMTK, CMTL, CMTM
CSWP, CSWR
CXKF, CXWP

If the code is not listed, the PCM has already been updated. Diagnose other causes using the SLX service manual and ETM.
If the code is listed, proceed to the repair procedure.


Repair Procedure

1. Write down the client’s radio presets and audio settings.

2. Note the fuel gauge reading, then disconnect the negative battery cable.

3. Remove the fuel fill cap.

4. If the tank is more than 1/2 full, drain or siphon fuel into a suitable container. Tighten the drain plug to 20 N·m (14 lb‑ft).

5. Raise the vehicle on a lift.

6. Clean the area around the fuel sending unit using brake cleaner and compressed air.

7. Remove the sending unit. Cover the tank opening to prevent contamination. Discard the old unit.


8. Install the new sending unit.

9. Lower the vehicle.

10. Refill the tank with the drained fuel and reinstall the fuel fill cap.

11. Reconnect the negative battery cable.

12. Re-enter radio presets and reset the clock.

13. Send the PCM to the vendor for reprogramming. Instructions are available on the iN under: Service Bay → Smart Cable.

14. Clear any remaining DTCs using a generic scan tool.


Client Information: This bulletin is intended for trained technicians with proper tools and equipment. Do not assume it applies to your vehicle; consult an authorized Acura dealer.

Thursday, May 1, 2025

Acura TSB 00-002

Acura Service Bulletin 00-002

Applies To:
1999–2003 3.2TL – ALL

Date: March 24, 2006
(Supersedes 00‑002, dated February 7, 2000)

Rear Door Sash Trims Wrinkled

Symptom

The rear door sash trim is wrinkled.

Probable Cause

The rear channel is too close to the upper sash.

Corrective Action

Have a competent automotive body repair shop replace the rear door sash trim and shim the rear channel away from the upper sash.

Parts Information

Left Rear Sash Trim: P/N 67866‑S0K‑A00ZA
Right Rear Sash Trim: P/N 67826‑S0K‑A00ZA
6 mm washer (1 per side): P/N 94101‑06800

Recommended Materials

3M Scotch‑Brite Molding Adhesive & Stripe Removal Disc: 3M P/N 051131‑07502
3M General Purpose Adhesive Remover:
– 3M P/N 051135‑08987 (California)
– 3M P/N 051135‑08984 (All Other States)

Warranty Claim Information

OP# Description FRT
829107 Replace left rear sash trim 2.3
829108 Replace right rear sash trim 2.3
829109 Replace both rear sash trims 4.6

Failed Part: P/N 67826‑S0K‑A00ZA
Defect Code: 07404
Symptom Code: 00101
Skill Level: Repair Technician

Out of warranty: Repairs after warranty expiration may be eligible for goodwill consideration by the District Parts & Service Manager or Zone Office. Approval must be obtained before work begins.


Repair Procedure

1. Lower the rear window.

2. Remove the inner door handle and door panel.
Refer to page 20‑12 of the 1999–03 3.2TL Service Manual, or search “DOOR PANEL REMOVAL” in the online manual.

3. Remove the plastic cover and rod protector.

4. Remove the rear channel, quarter glass, rear window, and run channel.
Refer to page 20‑16 of the service manual or search “REAR WINDOW REPLACEMENT.”

5. Remove the subseal and weatherstrip.


6. Remove the sash trim panel and door molding.


Body Shop Steps (7–14)

7. Remove the sash trim using a heat gun on low. If difficult, use a Scotch‑Brite Adhesive Removal Disc (under 2,800 RPM).


8. Remove adhesive residue with 3M Adhesive Remover, then clean with mild soap and water.

9. Remove adhesive backing from the front edge of the new sash trim. Align the cut and angle with the door frame.


10. Wet the door frame with mild soap and water (2 drops dish soap per gallon).

11. Peel backing while applying trim. Ensure even overhang and avoid air bubbles.


12. Starting at the front, use a plastic squeegee wrapped in a soft cloth to push water out.

13. From the middle, roll edges around the frame toward both ends.


14. Use a squeegee to smooth down remaining edges.



15. Reinstall the sash trim panel and door molding.

16. Reinstall the subseal and weatherstrip.

17. Glue a 6 mm washer to the top of the rear channel using super glue or equivalent.


18. Reinstall the rear window, quarter glass, rear channel, and run channel.

19. Reinstall the rod protector and plastic cover.

20. Reinstall the door panel and inner door handle.

21. Repeat steps 1–20 for the opposite side if needed.


Client Information: This bulletin is intended for trained technicians with proper tools and equipment. Do not assume it applies to your vehicle; consult an authorized Acura dealer.

Wednesday, April 2, 2025

Acura TSB 00-001

Acura Service Bulletin 00-001

Applies To:
1994–98 Integra 3‑Door – ALL
1999 Integra 3‑Door – from VIN JH4DC2 ... YS000001 thru JH4DC2 ... YS002822
1999 Integra 3‑Door – from VIN JH4DC4 ... YS000001 thru JH4DC4 ... YS006740

Date: February 14, 2000

Guide Channel Cover Comes Loose

Symptom

The guide channel cover comes loose from the window guide channel.

Probable Cause

Heat or previous removal has weakened the adhesive.

Corrective Action

Replace the cover.

Parts Information

Guide Channel Cover: P/N 72233‑SS0‑013

Required Materials

3M General Purpose Adhesive Cleaner: 3M P/N 051135‑08984
(Each container will clean about 100 vehicles.)

Warranty Claim Information

OP# Description FRT Template ID
826138 Replace guide channel cover (left side) 0.2 00-001A
827138 Replace guide channel cover (right side) 0.2 00-001B
826138 / 827138 Replace guide channel cover (both sides) 0.4 00-001C

Failed Part: P/N 72233‑SS0‑003
Defect Code: 061
Contention Code: A02
Skill Level: Repair Technician

Out of warranty: Any repair performed after warranty expiration may be eligible for goodwill consideration by the District Technical Manager or your Zone Office. You must request consideration and get a decision before starting work.


Repair Procedure

1. Remove and discard the affected guide channel cover.


2. Use adhesive cleaner to remove any adhesive residue from the window guide channel.

3. Peel the protective paper from the new cover, and press it firmly against the channel.

4. If necessary, replace the cover on the other side.


Customer Information: The information in this bulletin is intended for use only by skilled technicians who have the proper tools, equipment, and training to correctly and safely maintain your vehicle. These procedures should not be attempted by “do‑it‑yourselfers,” and you should not assume this bulletin applies to your vehicle. To determine whether this information applies, contact an authorized Acura automobile dealer.

Thursday, March 20, 2025

Acura ZDX Owners to Gain Access to Tesla Supercharger Network in June 2025

Acura ZDX owners will gain access to more than 20,000 select Tesla Superchargers across the United States starting in June 2025 with the availability of the first Acura-approved NACS-CCS DC fast-charging adapter. Approved adapters will better ensure a safe and reliable charging experience for Acura customers. The adapter was tested for safety performance and compatibility with the ZDX for use at any NACS DC fast-charging point and is the only DC fast charging adapter approved by Acura.

Customers can purchase the new Acura-approved NACS-CCS DC fast-charging adapter from authorized Acura dealerships in the United States starting in June, with pricing to be confirmed closer to market introduction. Acura ZDX owners will be notified via the Acura EV apps when adapters are available to purchase and, at that time, they will also be able to use the apps to locate authorized Supercharger locations. To better ensure a safe and reliable charging experience, Tesla requires  and, accordingly, Acura strongly recommends, the use of approved adapters when charging at Tesla Supercharger stations. Damage caused by using unapproved adapters may not be covered by vehicles' limited warranties.

Honda and Acura Charging Initiatives
By 2030, Honda and Acura EV owners will have access to approximately 100,000 DC fast-charge points across North America, including the Tesla Supercharger network, all-new IONNA DC fast-charging network and the EVgo and Electrify America charging networks.






Thursday, November 14, 2024

Acura ADX Makes World Debut

The Acura ADX is Acura's first-ever premium compact SUV, designed to cater to modern drivers seeking luxury and versatility. Here's what stands out:

  • Performance: It features a 1.5L VTEC Turbo engine delivering 190 horsepower, with options for front-wheel drive or all-wheel drive. The ADX offers a smooth and dynamic driving experience, enhanced by its advanced suspension and steering systems.
  • Design: The ADX boasts a sleek and sporty exterior, with premium styling elements like the Diamond Pentagon Grille and LED lighting. The A-Spec package adds performance-inspired touches, including 19-inch alloy wheels and black trim accents.
  • Interior: Inside, you'll find a spacious and modern cabin with a 10.2-inch digital gauge cluster, a 9.0-inch touchscreen, and premium materials. Features like dual-zone climate control and a wireless phone charger come standard.
  • Technology: The ADX is equipped with advanced safety and driver-assist features, as well as a premium audio system. It also offers multiple driving modes, including Sport and Snow, to adapt to various conditions.
  • Pricing: The ADX starts at $35,000 for the base model, with higher trims like the A-Spec and A-Spec with Advance Package priced up to $44,000.
This SUV is designed to compete with other luxury compact SUVs while maintaining Acura's reputation for quality and performance.














Popular Posts

Search it!
